A7V Battle Tank (Germany)

The A7V was the German response to the initial successes of the British tanks forces on the Western Front in 1916 (WW1). It was first proposed towards the end of 1916, and the prototype was ready by the middle of 1917. Like several other tanks of the period, it was based on the American Holt Tractor, which provided the tracks. Despite suffering from many obvious flaws, the German general staff was aware that they did not have time to produce an improved design, and at the end of 1917 ordered 100, of which only one third were ever produced. The design suffered from a series of faults. It lacked the mobility needed to operate amongst the trenches of the western front, and could not operate in any type of heavy ground without becoming stuck. It contained a great deal of weaponry - one main 5.7 cm gun firing forward, and as many as seven machine guns facing in other directions. The crew of 18 came from three separate branches of the German military - the artillery, the engineers and the infantry - which was said to have reduced the effectiveness of the tank. The A7V saw some service during the summer of 1918, but had little impact on the fighting, and was massively outnumbered by the allied tank corps.




The A7V was a tank introduced by Germany in 1918, near the end of World War I. 100 examples were ordered for the spring of 1918, but only 20 were delivered. They saw action from March to October of that year, and were the only tanks produced by Germany in World War I to see operational use.

History

Following the appearance of the first British tanks on the Western Front, the Allgemeines Kriegsdepartement, 7. Abteilung, Verkehrswesen ("General War Department, 7th Branch, Transportation"), was formed in September 1916.

The project to design and build the first German tank was placed under the direction of Joseph Vollmer, a Reserve Captain and engineer. The new tank was to be a universal chassis which could be used as a base for both a tank and unarmoured Überlandwagen ("Over-land vehicle") cargo carriers. It was based on the Holt tractor, parts for which were obtained from Austria, where it was produced under licence.

The first prototype was completed by Daimler-Benz and tested in April 1917. A wooden mockup of a final version was completed in May 1917. The first pre-production A7V was produced in September 1917, followed by the first production model in October 1917.

Naming

The tank's name was derived from that of its parent organization, Allgemeines Kriegsdepartement, 7. Abteilung, Verkehrswesen. In German the tank was called Sturmpanzer-Kraftwagen (roughly "assault armoured motor vehicle").

Design

The A7V was over seven metres long and three metres wide. The height varied up to three metres. The tank had 20 mm of steel plate at the sides and 30 mm at the front; however the steel was not hardened armor plate, which reduced its effectiveness. It was thick enough to stop machine gun and rifle fire, but not larger calibres. This offered protection comparable to the thinner armor of other tanks of the period, which used hardened steel.

The crew normally consisted of up to sixteen soldiers and two officers: commander, driver, mechanic, mechanic/signaller, twelve infantrymen (six machine gunners, six loaders), and two artillerymen (main gunner and loader).

The A7V was armed with six 7.9 mm MG08/15 machine guns and a 5.7 cm gun mounted at the front. The 'female' variant had two more machine guns in place of the main gun. It is not entirely clear how many started this way or were converted. Some sources say only chassis 501 saw combat as a female.

Power came from two centrally mounted Daimler 4-cylinder engines delivering 100 hp (74 kW) each. The top speed was about 15 km/h on roads and 5 km/h across country. The A7V carried 500 liters of fuel (132 imperial gallons).

It was as slow as other tanks of the day, but had very poor off-road capability and was prone to getting stuck. The large overhang at the front and low ground clearance meant trenches or very muddy areas were impassable. This was worsened by the fact that the driver could not see the terrain directly in front of the tank, due to a blind spot of about 10 meters. However, on open terrain it could be used to some success and offered more firepower than the armoured cars that were available. Power to weight ratio was 6.8 hp/ton (5.1 kW/ton), trench crossing: 7 ft (2.3 m), ground clearance: 7.5 to 15.75 in (200 to 400 mm).

30 chassis were assigned for completion as Überlandwagen supply carriers, but not all were completed before end of the war.

The design of the A7V featured on the Tank Badge of 1921, awarded to commemorate service in the German Panzer forces of 1918.

Combat history

The A7V was first used in combat on 21 March 1918. It was deployed north of the St.Quentin Canal. The A7Vs helped stop a minor British breakthrough in the area, but otherwise saw little combat that day.

The first tank vs. tank fight in history took place on the 24 April 1918 when three A7Vs (including chassis number 561, known as "Nixe") taking part in an attack with infantry incidentally met three Mark IVs (two Female machine gun tanks and one Male with 6 pounder guns) near Villers-Bretonneux. During the battle tanks on both sides were damaged. According to the lead tank commander, 2nd Lt Frank Mitchell, the machine gun armed Female Mk IVs fell back after being damaged by armor piercing bullets. They were unable to damage the A7Vs with their own machine guns. Mitchell then attacked the lead German tank commanded by 2nd Lt Wilhelm Biltz with the 6 pounders of his own tank and knocked it out. He hit it three times, and killed five of the crew when they bailed out. He then went on to rout some infantry with case shot. The two remaining A7Vs in turn withdrew. As Lt. Mitchell's tank withdrew from action, 7 Whippet tanks also engaged the infantry. Four of these were knocked out in the battle, and it is unclear if any of them engaged the retreating German tanks. Lt. Mitchell's tank lost a track towards the end from a mortar shell and was abandoned. The damaged A7V was later recovered by German forces.

A7V Tank, Mephisto, at Queensland Museum in Brisbane, Australia

All 18 available A7Vs had been put into action that day with limited results; two toppled over into holes, some encountered engine or armament troubles. After a counterattack, three ended up in Allied hands. One was unusable and scrapped, one used for shell testing by the French, and the third taken by the Australians.

The A7V was not considered a success and other designs were planned by Germany, however the end of the war meant none of the other tanks in development, or planned ones, would be finished (such as the Oberschlesien, K-Wagen, LK I or LK II). The A7Vs final use in WW1 was in October 1918; a number were scrapped before the war ended in November.

The extremely limited production of twenty made a very limited contribution, and most of the tanks (less than a hundred) that were fielded in action by Germany in World War I were captured French or British tanks (Beutepanzer). In contrast, the French had produced over 3,600 of their FT-17, the most produced tank of World War I, and the British over 2,500 of their Mark I to V tanks.
